Construction Fence

Product Overview



The fenceplastic.com Heavy-Duty Construction Fence system is engineered for temporary job-site containment, perimeter security, and pedestrian hazard control. Built using structural-grade virgin HDPE polymers combined with high-density resin panels or hot-dip galvanized reinforcing frames, this system withstands aggressive site environments, repeated transport cycles, and prolonged ultraviolet exposure.
Designed specifically for general contractors, civil engineering firms, and industrial rental fleets, our temporary fencing delivers high impact resistance, rapid tool-free installation, and a minimum 5-to-7-year field service life in extreme weather zones.





Key Features



High-Density Virgin Polymer Composition:

Extruded using 100% virgin HDPE base resin integrated with hindered amine light stabilizers (HALS), preventing premature micro-cracking and color fading under continuous solar radiation.

01

Reinforced Structural Interlocks:

Precision-molded corner joints and vertical ribbing distribute kinetic impacts evenly, preventing panel warping when subjected to heavy site traffic or wind shear.

02

Modular Base Stability:

Compatible with injection-molded, concrete-filled, or recycled PVC weighted feet designed to maintain structural rigidity on unpaved ground, asphalt, and concrete slabs.

03

Rapid Deployment Design:

Interlocking pin-and-hook corner connections allow a two-person crew to install up to 100 linear meters of perimeter fencing per hour without specialized heavy machinery.

04

High-Visibility Safety Profiles:

Standard OSHA-compliant high-visibility orange, safety yellow, or project-specific RAL color matching available to demarcate danger zones clearly.

05



Technical Specifications



Parameter

Specification

Primary Material

Virgin HDPE (High-Density Polyethylene) with UV Stabilizers

Standard Panel Dimensions (L x H)

2000mm x 1200mm / 2500mm x 2000mm (Custom dimensions available upon request)

Mesh Aperture / Slat Configuration

50mm x 50mm square grid or vertical flat-slat architectural profile

Wall Thickness

3.5mm – 5.0mm (Load-bearing structural ribs)

UV Additive Concentration

3% to 5% Chimassorb UV stabilizer package

Base Options

Blow-molded HDPE shell filled with concrete or recycled rubber (Weight: 20kg - 30kg)

Operating Temperature Range

-40°C to +80°C

Tensile Strength

Greater than 24 MPa (ASTM D638 test standard)

Certifications & Compliance

ISO 9001 Quality Management, CE Marked, RoHS Compliant, ISPM 15 Export Packaging



Blue Barrier Mesh Fence



Applications

Commercial Construction Sites: Securing perimeter boundaries to restrict unauthorized public access and comply with local municipal safety codes.


Civil Infrastructure & Roadworks: Rapid lane closure demarcation, excavation trench guarding, and highway maintenance zone zoning.


Utility & Solar Farm Projects: Large-scale boundary delineation for remote renewable energy installations requiring corrosion-resistant perimeter barriers.


Industrial Plant Turnarounds: Temporary zoning for refinery maintenance, factory expansions, and restricted internal logistics corridors.


Municipal Events & Public Works: Crowd control management and pedestrian routing for outdoor civic projects and festivals.





Installation & Usage

Site Layout Marking: Survey the perimeter line and mark anchor points for base placement at standard intervals matching the panel length (e.g., 2.0m or 2.5m centers).


Base Positioning: Place the weighted base feet (concrete-filled HDPE or recycled rubber blocks) firmly on a leveled surface. Ensure the dual-socket receptacles face the intended alignment direction.


Panel Insertion: Insert the vertical tubular legs or integrated side pins of the first fence panel into the base foot receptacles.


Interlocking Connection: Align the second panel adjacent to the first. Secure the upper and lower connecting clamps or hook-and-eye pins to lock the panels together rigidly.


Wind Bracing (For High-Wind Zones): Install diagonal stabilizer struts fixed to weighted ground anchors at every 10-meter interval on sites exposed to high lateral wind loads.

Yellow Plastic Construction Fencing Roll




OEM Solutions


We support full-scale OEM and ODM manufacturing partnerships for global rental companies, brand distributors, and industrial suppliers:

01/

Custom Color Matching: Production runs matched to precise RAL or Pantone color codes to align with corporate branding or municipal mandates.

02/

Embedded Brand Logo Plates: Laser-etched or molded-in company logos and contact details directly onto the fence panels and base feet for rental asset tracking and loss prevention.

03/

Customized Dimensions: Tailored panel heights, altered mesh densities, and specialized wire gauges engineered to meet specific regional building codes or engineering drawings.

04/

Private Label Packaging: Customized pallet configurations, barcode labeling, and instruction manuals printed in local languages for direct-to-warehouse delivery.



Quality Control

Manufacturing integrity is verified through rigorous factory testing protocols prior to container loading:

UV Accelerated Weathering Test:

Samples undergo QUV accelerated weathering chamber testing (ASTM G154) simulating 5 years of intense solar exposure to verify color retention and tensile strength preservation.

Drop & Impact Testing:

Finished panels undergo pendulum impact testing at sub-zero and elevated temperatures to ensure cold-weather impact resistance without shattering.

Dimensional Verification:

Laser measurement systems monitor extrusion profiles continuously to maintain exact tolerances on panel interlocks and tube diameters.

Raw Material Traceability:

Incoming virgin resin batches are tested for melt flow index (MFI) and density before entering the extrusion line.





FAQ





Q: How do these HDPE fence panels perform under high wind loads compared to traditional chain-link fence panels?

A: Solid or semi-solid HDPE panels experience higher wind drag than open chain-link mesh. For high-wind zones, we recommend utilizing slotted/mesh-profile panels that allow air permeability (reduction of wind sail effect) and pairing them with our diagonal stabilizer struts and 30kg weighted base feet to maintain structural stability up to Beaufort Scale Force 8.

Q: What is your standard Minimum Order Quantity (MOQ) for custom-branded orders?

A: For standard stock items in high-visibility orange or white, our MOQ is one 20-foot container (20ft GP). For fully customized colors, private label embossing, or non-standard dimensions, the MOQ is one 40-foot high-cube container (40ft HC) to optimize production setup and freight efficiency.

Q: What container loading capacities should we expect for shipping logistics planning?

A: A standard 40-foot high-cube (40ft HC) container typically accommodates approximately 400 to 500 panels along with corresponding base feet, stacked on ISPM 15-compliant heat-treated wooden pallets secured with heavy-duty strapping. Exact quantities vary based on panel thickness and base weight.

Q: What trade terms (Incoterms) and payment structures do you support for international B2B buyers?

A: We primarily support FOB, CIF, and DDP shipping terms via major ports. Standard payment terms are structured via Telegraphic Transfer (T/T), with a 30% production deposit and the remaining 70% balance payable against copy of the Bill of Lading and third-party inspection reports (e.g., SGS or BV). Irrevocable Letter of Credit (L/C) at sight is also accepted for verified tier-one accounts.



modular-1
RFQ

To receive a formal quotation with tiered volume pricing, freight estimates, and technical data sheets, please provide the following project details via our website or direct email:
Product Specification: Panel dimensions, mesh type, and desired color.
Order Quantity: Total linear meters or container load count (20ft / 40ft container).
Base Requirement: Concrete-filled HDPE feet, recycled rubber feet, or bare panels only.
Destination Port / Job Site Zip Code: For accurate CIF or DDP logistics cost calculation.
Customization Needs: OEM logo embossing or specific packaging requirements.

We are one of the most reliable construction fence manufacturers and suppliers in China, specialized in providing high quality customized products. We warmly welcome you to wholesale discount construction fence for sale here from our factory. Contact us for pricelist and free sample.
